Manylebau
Ardal Torri: 1500 * 3000mm
Cutting Speed:200mm/s
Fformat Graffig Cefnogir: AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Cymhwysiad: Torri Laser
Amod: Newydd
Cutting Thickness:0-12mm
CNC neu Ddim: Ydw
Modd Oeri: Oeri Dŵr
Control Software:Cypcut FSCUT 2000
Man Tarddiad: Anhui, Tsieina (tir mawr)
Enw Brand: ACCURL
Ardystiad: CE, ISO, SGS
Warranty:3 years, 3 years
Working size:1500*3000mm
Laser power:1000w
Laser generator:Raycus 1000W fiber laser generator
Controller:Cypcut FSCUT 2000
Laser head:Raytools or WSX
Motor and driver:Japan YASKAWA servo motor
Reducer:France MOTOVARIO
Size:4760*2190*1980mm
The machine parameter.
| Ardal weithio | 1500 * 3000mm |
| Laser brand | Raycus 1000w |
| Pŵer laser | 300w/500w/700w/1000w/1500w/2000w |
| Tabl gweithio | Sawtooth worktable |
| System reoli | Cypcut FSCUT 2000 controller |
| Drive system | Japan YASKAWA servo driver and motors |
| Canllaw rheilffordd | Taiwan Hiwin Linear rail guide |
| Trosglwyddo | X,Y by gear, Z by ball screw |
| Cooling chiller | water cooling system |
| Lled y llinell isaf | ≤0.02mm |
| Cywirdeb y sefyllfa | 0.025mm |
| Cyflymder torri | 80m / mun |
| Meddalwedd rheoli | Cypcut system |
| Graphic format support | PLT, DXF, BMP, JPG ,AI ,ect |
| Amgylchedd gweithio | 0-45℃, |
| Cyflenwad Pŵer | 380V+/-10% 50Hz |
The different laser power cutting parameter, choose the suitable laser.
Dur Carbon | 0.4-6mm | 0.4-10mm | 0.4-12mm | 0.4-14mm | 0.4-16mm |
Dur Di-staen | 0.4-3mm | 0.4-4mm | 0.4-5mm | 0.4-6mm | 0.4-8mm |
Alwminiwm | 0.4-2mm | 0.4-3mm | 0.4-3mm | 0.4-4mm | 0.4-6mm |
Pres | 0.4-3mm | 0.4-3mm | 0.4-3mm | ||
Fiber Power | 500W | 750W | 1000W | 1500W | 2000W |
Package and shipping
| Step 1 | Check every fiber laser cutting machine parts again, ensure no one lose. |
| Step 2 | All the parts put in laser cut machine body, and package by film, keep it safe during sea shipping. |
| Step 3 | Put laser machine in plywood box. |
| Step 4 | Ship to Qingdao port |
Warranty and After sale service
| Warranty: 36 months |
| Strict inner quality control in the whole production process |
| English version manual/software manual can be offered |
| Before shipping, the operating test video and photo will give |
| Engineers available to offer service overseas |
| Whole lifetime maintenance free of charge |
| During warranty period, the damaged parts can be replaced free of charge |
| Two service teams offer service from Monday to Sunday |
| Every request can be given feedback within 2 hours |
Cwestiynau Cyffredin
Q: Is sample available?
A: Yes, sample is available.
Q:How to place OEM order to us?
A: Please view our website and click the link to inform our service people what product you are interested in.
B: Our people will offer you more information that maybe helpful for you. We will offer you custom solution depend on your demand.
C: Please confirm the order with our service people.
D: We will start to produce once getting your prepaid money. And we will keep you informed any problem during the production.
E: We will inform you to pay the rest payment when the order is ready to ship.
F: We will arrange the shipping follow the order instruction, by sea, by air or by express.
Q: How to ship the order?
A: Please inform us your instruction, by sea, by air or by express, any way is OK for us.
B: We have very professional forwarder to provide the best shipping cost, service and guarantee. (The fiber laser machine package size is big, so only can use sea shipment)
Q: How to pay?
A: Via T/T, L/C, PayPal and Western Union
Q:Why to choose us?
A: 10 years’ Great Experience in laser machine.
B: Professional R&D (Research and Development) team for designing and manufacturing.
C: Professional Trading service team for smoothly business with YOU.
D: The best One-Stop sourcing service.
E: Saving your a lot of time and money.
